Illustrated Parts List

SM1399-1 – 19JUN06 11

Figure 1 COVER AYs

Item Part No. Description Quantity Notes

1 3F6374 SCREW - tapping, 1.7 x 4.0, nickel

1 8

2 3F9415 COVER - back, C643

1 1

3F9464 COVER - back, C603

1 1

3 3F9414 COVER - front, C643

1 1

3F9463 COVER - front, C603

1 1

4 3F9423 CARD DOOR AY - C643

1 1

3F9466 CARD DOOR AY - C603

1 1

5 3F9424 SHAFT - card door

1 1

6 3F9425 SPRING - card door

1 1

7 3F9421 SHAFT - battery door

1 1

8 3F9422 SPRING - battery door

1 1

9 3F9419 BATTERY DOOR - C643

1 1

3F9465 BATTERY DOOR - C603

1 1

------ 3F9618 PLATE - data, C643

1 1 Not visible in the graphic.

------ 3F9619 PLATE - data, C603

1 1 Not visible in the graphic.

------ 3F6387 STRAP - wrist

1 1 Not visible in the graphic.

------ 3F9428 CUSTOM DOCK INSERT

1 1 Not visible in the graphic.
