Kodak EasyShare C643 Service Manual

SERVICE MANUAL
16 19JUN06 – SM1399-1
Section 3: Diagnostics
Error Codes
E00
E12
E14
E15
E20
Description Recommended Action
A communication error occurred between the
MCU and the 16-BIT MAIN CPU.
1. Do “
Upgrading the Firmware Using the MEMORY
CARD” on Page 74.
2. Install a new MCU BOARD.
Description Recommended Action
An error occurred when the LENS was retracted after
energizing the CAMERA.
1. Check the FPC CABLE from the MOTOR to the
CONNECTOR J3 on the MCU BOARD.
2. Install a new MCU BOARD.
3. Install a new LENS AY.
Description Recommended Action
An error occurred when the LENS was extended after
energizing the CAMERA.
1. Check the FPC CABLE from the MOTOR to the
CONNECTOR J3 on the MCU BOARD.
2. Install a new MCU BOARD.
3. Install a new LENS AY.
Description Recommended Action
An error occurred when the STEP MOTOR was reset
after energizing the CAMERA.
1. Check the FPC CABLE from the MOTOR to the
CONNECTOR J3 on the MCU BOARD.
2. Install a new MCU BOARD.
3. Install a new LENS AY.
Description Recommended Action
An error occurred when the CAMERA was writing to the
NANDFLASH memory.
1. Do “
Upgrading the Firmware Using the MEMORY
CARD” on Page 74.
2. Install a new MCU BOARD.

Kodak EasyShare C643 Specifications

General

Brand	Kodak
Model	EasyShare C643
Category	Digital Camera
Language	English
