SERVICE MANUAL
30 19JUN06 – SM1399-1
Checkout Procedures
Checking the General Functions of the CAMERA
Important
Do these procedures before returning the CAMERA to the customer.
[1] Install the 5 V AC ADAPTER to:
• CAMERA DOCK
• source of power
[2] Connect the CAMERA DOCK to the computer with the USB CABLE.
[3] Remove the BATTERY from the CAMERA.
[4] Install the CAMERA on the CAMERA DOCK. See “
Configurations for the CAMERA DOCK” on Page 6.
[5] Check that the STATUS LED on the CAMERA DOCK illuminates green.
[6] Remove the CAMERA from the CAMERA DOCK.
[7] Install:
• CRV3 BATTERY in the CAMERA
• CAMERA on the CAMERA DOCK
[8] Check:
• none of the LEDs for the BATTERY on the CAMERA DOCK illuminate green
• STATUS LED on the CAMERA DOCK illuminates green
[9] Remove:
• CAMERA from the CAMERA DOCK
• CRV3 BATTERY from CAMERA
[10] Install:
• Ni-MH BATTERY in the CAMERA
• CAMERA on the CAMERA DOCK
[11] Check:
• one or more of the LEDs for the BATTERY on the CAMERA DOCK illuminate green
• STATUS LED on the CAMERA DOCK illuminates green
[12] Remove the CAMERA from the CAMERA DOCK.
[13] Energize the CAMERA.
[14] Check that the CAMERA energizes.
[15] De-energize the CAMERA.
[16] Remove the BATTERY from the CAMERA.
[17] Insert the MEMORY CARD into the CAMERA.
[18] Install the CAMERA on the CAMERA DOCK. See “
Configurations for the CAMERA DOCK” on Page 6.
[19] Rotate the MODE DIAL to the “AUTO” position.
[20] Check the energize sequence:
• green LED illuminates on the CAMERA DOCK
• green LED to the right of the VIEWFINDER
– blinks 2 times
– remains illuminated
• error code does not display
[21] De-energize the CAMERA.
[22] Remove the CAMERA from the CAMERA DOCK.
To Next Page
