SERVICE MANUAL
36 19JUN06 – SM1399-1
Section 4: Adjustments
MCU BOARD/LENS AY - “Shutter Delay”
Adjustment Specification
Important
Do not use the CAMERA DOCK in this procedure.
Prerequisites:
None
To Check:
You cannot check this adjustment.
To Adjust:
Important
The C643 CAMERA and MEMORY CARDS are used for the examples in this procedure.
The procedure can be used for:
C643 CAMERA
C603 CAMERA
If you are doing a calibration of the C603 CAMERA, use the correct MASTER CAMERA and MEMORY CARDS
made for that CAMERA.
[1] Do Preparing the C643_C603 Shutter_Delay MEMORY CARD
on Page 71.
[2] Insert:
new BATTERY with a full charge into the C643 CAMERA
•“C643_C603 Shutter_Delay MEMORY CARD into the CAMERA
[3] Set the LIGHT BOX to LV15.
[4] Place the center of the LENS against the screen of the LIGHT BOX.
[5] Rotate the MODE DIAL to AUTO to execute the test.
[6] If the MONITOR LCD displays Date and time have been reset, select CANCEL.
[7] When the test is completed, check that the MONITOR LCD displays Shutter Calibrate OK.
[8] De-energize the CAMERA.
[9] Remove the MEMORY CARD from the CAMERA.
Purpose: To set the parameters for the speed of the SHUTTER.
Do When: After installing a new MCU BOARD/LENS AY.
Exposure of the images displayed on the MONITOR LCD is too high or too low.
Specification: No failure messages display.
Special Tools: Computer with a MEMORY CARD READER/WRITER
BATTERY
LIGHT BOX
SD/MMC MEMORY CARDS
