SERVICE MANUAL
40 19JUN06 – SM1399-1
CCD - “AWB/ ISO/DBP”
Adjustment Specification
Important
Do not use the CAMERA DOCK in this procedure.
Prerequisites:
[1] Do MASTER CAMERA - Calibration of the MASTER CAMERA on Page 38.
To Check:
You cannot check this adjustment.
To Adjust:
Important
The C643 CAMERA and MEMORY CARDS are used for the examples in this procedure.
The procedure can be used for:
C643 CAMERA
C603 CAMERA
You will need the files made from the procedure MASTER CAMERA - Calibration of the MASTER CAMERA
on
Page 38.
[1] Do
Preparing the C643_C603 AWB_ISO_DBP MEMORY CARD on Page 65.
[2] Make a copy of the following files from the C643_C603 Master Camera MEMORY CARD:
•“BIG_LAMP.fig
•“BoxID_ref.fig
•“CameraID_ref.fig
•“K_RESULT.txt
•“CamerID_ref.fig
•“Small_LAMP.fig
[3] Place these 6 files in the folder Batch on the C643_C603 AWB_ISO_DBP MEMORY CARD.
[4] Insert:
new BATTERY with a full charge into a C643 CAMERA
•“C643_C603 AWB_ISO_DBP MEMORY CARD into the CAMERA
[5] Set the LIGHT BOX to:
LV10
color temperature 5800 K
Purpose: To set the values for Automatic White Balance, ISO, and ID of the CAMERA.
Do When: After installing a new MCU BOARD/LENS AY.
Specification: The failure message does not display.
Special Tools: Computer with a MEMORY CARD READER/WRITER
BATTERY
LIGHT BOX
SD/MMC MEMORY CARDS
