Adjustments
SM1399-1 – 19JUN06 39
[3] Place the CAMERA in front of the LIGHT BOX.
• The LENS must be within 3 mm (0.1 in.) of the screen, but not touching the screen of the LIGHT BOX.
• The center of the LENS must be placed in the center of the light.
[4] Set the LIGHT BOX to LV10.
[5] Rotate the MODE DIAL to “AUTO” to execute the test.
[6] If the MONITOR LCD displays “Date and time have been reset”, select “CANCEL”.
[7] When the test is completed, check that the MONITOR LCD displays “Big LB OK”.
[8] De-energize the CAMERA.
Important
You must use the same LIGHT BOX when using this MEMORY CARD for calibration of other C643 CAMERAS.
[9] Remove the MEMORY CARD.
[10] Check that the following 4 additional files were written on the MEMORY CARD:
•“BIG_LAMP.fig”
•“BoxID_ref.fig”
•“CameraID_ref.fig”
•“K_RESULT.txt”
[11] Do Step 2
to Step 6 again.
[12] When the test is completed, check that the MONITOR LCD displays “Small LB OK”.
[13] De-energize the CAMERA.
[14] Remove the MEMORY CARD.
[15] Check that the following 2 additional files were written on the MEMORY CARD:
•“CamerID_ref.fig”
•“Small_LAMP.fig”
Note
These 6 files are necessary before you do Preparing the “C643_C603 AWB_ISO_DBP” MEMORY CARD on
Page 65.
[16] If the MONITOR LCD displays a failure message, do the correction:
Postrequisites:
None
Failure Cause Correction
“W/O Shutter K” The calibration of the SHUTTER
was not correct.
Do:
1. “
Preparing the “C643_C603 Shutter_Delay”
MEMORY CARD” on Page 71
2. Preparing the “C643_C603 Master Camera”
MEMORY CARD on Page 68 again
“Memory Fail” An occasional failure occurred
during a test of the memory.
1. Do Preparing the “C643_C603 Master Camera”
MEMORY CARD on Page 68 again.
2. If the message occurs again, check the hardware.
“ISO Cal Fail” A failure occurred during the
calibration.
1. Check:
• LIGHT BOX
• LV value
2. Do Preparing the “C643_C603 Master Camera”
MEMORY CARD on Page 68 again.
To Next Page
