Adjustments
SM1399-1 – 19JUN06 41
[6] Place the center of the LENS against the screen of the LIGHT BOX.
[7] Rotate the MODE DIAL to “AUTO” to execute the test.
[8] If the MONITOR LCD displays “Date and time have been reset”, select “CANCEL”.
[9] When the test is completed, check that the MONITOR LCD displays “ISO Cal OK”.
Note
The result file “K_RESULT.TXT” is written to the MEMORY CARD.
[10] De-energize the CAMERA.
[11] Remove the MEMORY CARD from the CAMERA.
[12] If the MONITOR LCD displays the failure message “ISO Cal Fail”:
• open the file “K_RESULT.TXT” to obtain the type of failure
• do the necessary correction
Postrequisites:
None
Failure Cause Correction
“W/O Shutter K” The calibration of the SHUTTER was
not correct.
Do:
1. MCU BOARD/LENS AY - “Shutter Delay”
on
Page 36
2. CCD - “AWB/ ISO/DBP” on Page 40 again
“Memory Fail” An occasional failure occurred during
a test of the memory.
1. Do CCD - “AWB/ ISO/DBP”
on Page 40
again.
2. If the message occurs again, check the
hardware.
“ISO Cal Fail” A failure occurred during the
calibration.
1. Check:
• LIGHT BOX
• LV value
2. Do CCD - “AWB/ ISO/DBP”
on Page 40
again.
