SERVICE MANUAL
14 19JUN06 – SM1399-1
Figure 3 LENS AY AND MCU BOARD, POWER BOARD AND FRAME AY, SHUTTER BOARD
Item Part No. Description Quantity Notes
1 ------ SOLDER JOINTS
3 5
2 3F9583 LENS AND MCU BOARD AY
3 1See “MCU BOARD” on Page 47 for details on
where the colored WIRES are soldered to the
MCU BOARD.
3 3F9417 POWER BOARD AND FRAME AY
3 1See “POWER BOARD AND FRAME AY” on
Page 44 for special replacement instructions.
4 3F9418 BOARD - shutter
3 1
5 3F9426 ESD PLATE - monitor LCD
3 1
6 3F6412 SCREW - tapping, 1.7 x 3.0, black
3 4
7 3F9416 BOARD - mcu
3 1See “MCU BOARD” on Page 47 for details on
where the colored WIRES are soldered to the
MCU BOARD.
8 3F9420 LENS AY
3 1
9 3F9443 ESD PLATE - speaker
3 1
10 ------ HOOK A
3 1 Release the LENS AY AND MCU BOARD from
the HOOK A.
11 ------ HOOK B
3 1 Release the SHUTTER BOARD from the
HOOK B.
12 ------ TAB
3 1 Release the LENS AY from the TAB.
------ 3F6204 FUSE - 1.25 A, F3
3 1See “POWER BOARD - 1 of 2” on Page 93.
------ 3F6205 FUSE - 2.5 A, F1, F2
3 1See “POWER BOARD - 2 of 2” on Page 94.
