Adjustments
SM1399-1 – 19JUN06 43
[7] If the MONITOR LCD displays “Date and time have been reset”, select “CANCEL”.
[8] Press the SHUTTER BUTTON to execute the test.
[9] Check that the test runs 6 times.
[10] When the test is completed, check that the MONITOR LCD displays “OK”.
[11] De-energize the CAMERA.
[12] Remove the MEMORY CARD from the CAMERA.
[13] Did the MONITOR LCD display the failure message “NG”?
[14] Capture some images at a variation of zoom positions of the LENS.
[15] Review the images on the MONITOR LCD.
[16] Check that the images are not too dark or too light.
[17] Press the “T” BUTTON to increase the magnification of the images to the maximum.
[18] Check that the images on the MONITOR LCD are in focus.
Postrequisites:
None
Yes No
a. Install a new LENS AY AND MCU BOARD.
b. Do Step 4
- Step 12 again.
c. If the MONITOR LCD displayed the failure
message “NG” again, install a new POWER
BOARD AND FRAME AY.
d. Do Step 4
- Step 12 again.
Continue with Step 14
.
To Next Page
