Replacements
SM1399-1 – 19JUN06 45
To Install:
Important
You must do this procedure when you do a replacement of the POWER BOARD AND FRAME AY.
[1] Compare the serial number of the CAMERA with the “Beginning Serial Number”:
[2] Is the serial number the same or higher than the “Beginning Serial Number”?
[3] Remove the RESISTOR R13 from the new replacement POWER BOARD AND FRAME AY.
Note
See “POWER BOARD - 2 of 2” on Page 94 to locate the RESISTOR R13.
[4] Discard the RESISTOR R13.
[5] Remove the RESISTOR R13 from the old POWER BOARD AND FRAME AY.
[6] Install:
• RESISTOR R13 on the new POWER BOARD AND FRAME AY
• new POWER BOARD AND FRAME AY
[7] Assemble the CAMERA.
Postrequisites:
None
CAMERA Beginning Serial Number
C643 KCGFN61713506
C603 KCGFP61901199
No Yes
Continue with Step 3
. 1. Install a new POWER BOARD AND FRAME AY.
2. Advance to Step 7
.
To Next Page
