Kodak EasyShare DX4530 User Manual

1
1 Getting Started
Install Software First
Install the software from the Kodak EasyShare software CD before connecting
the camera (or optional camera dock) to the computer. Failure to do so may
cause the software to load incorrectly.
See the Quick Start Guide or Installing the Software, page 55.
Need This User Guide in Larger Print?
1 See www.kodak.com/go/dx4530support.
2 Navigate to the Manuals section.
3 Click View as PDF to open the User’s Guide.
4 On a Windows OS-based computer or Mac OS 8.6 or 9.x:
m From the File menu, select Print.
m In the Print window, select Fit to Page.
On Mac OS X:
m From the File menu, select Page Setup.
m Change Scale to 200%.
5 Print as usual.

Kodak EasyShare DX4530 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Digital zoom	3.3 x
Optical zoom	3 x
Combined zoom	10 x
Focal length range	8 - 24 mm
Metering	automatic: multi-pattern TTL-AE
Interface	Dock Compatibility - KODAK EASYSHARE Camera Dock I, II and KODAK EASYSHARE Printer Dock 4000
Cable type	1 x A/V cable, 1 x USB cable
Minimum RAM	64 MB
Minimum processor	233 MHz
Dimensions (WxDxH)	111 x 66 x 39 mm
Camera shutter speed	1/2-1/1700 s
Minimum storage drive space	200 MB
Minimum system requirements	CD-ROM USB
Focal length (35mm film equivalent)	38 - 114 mm
Viewfinder type	Optical
Internal memory	32 MB
Compatible memory cards	mmc, sd
Display diagonal	1.8 \
I/O ports	1 x USB 1 x composite video/audio output 1 x docking station 1 x DC power input
Bundled software	KODAK EASYSHARE Software
Self-timer delay	10 s
Tripod mounting supported	Yes
Product color	Silver
Flash modes	Red-eye reduction

Weight and Dimensions

Weight	210 g
