Kodak EasyShare DX4530 User Manual

67
Chapter 9
Transferring Pictures and Videos
To transfer pictures and videos from your camera to your computer:
1 Place the camera in the camera dock. The
camera can be on or off.
If the battery is being charged, charging
pauses, then resumes after pictures and
videos are transferred.
2 Press the Connect button.
The Power/Transfer light blinks green
while the pictures are transferring.
3 For details on printing and emailing, see the Quick Start Guide or the
Kodak EasyShare software Help.
NOTE: After transferring pictures and videos, leave the camera in the camera
dock. Eight minutes after the transfer is complete, the camera dock
resumes charging as necessary.
Caution When Using a Tripod
Do not connect a tripod to the camera dock. Remove the camera from the
camera dock and connect the tripod directly to the camera.
Connect
Power/Transfer
light

Kodak EasyShare DX4530 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Digital zoom	3.3 x
Optical zoom	3 x
Combined zoom	10 x
Focal length range	8 - 24 mm
Metering	automatic: multi-pattern TTL-AE
Interface	Dock Compatibility - KODAK EASYSHARE Camera Dock I, II and KODAK EASYSHARE Printer Dock 4000
Cable type	1 x A/V cable, 1 x USB cable
Minimum RAM	64 MB
Minimum processor	233 MHz
Dimensions (WxDxH)	111 x 66 x 39 mm
Camera shutter speed	1/2-1/1700 s
Minimum storage drive space	200 MB
Minimum system requirements	CD-ROM USB
Focal length (35mm film equivalent)	38 - 114 mm
Viewfinder type	Optical
Internal memory	32 MB
Compatible memory cards	mmc, sd
Display diagonal	1.8 \
I/O ports	1 x USB 1 x composite video/audio output 1 x docking station 1 x DC power input
Bundled software	KODAK EASYSHARE Software
Self-timer delay	10 s
Tripod mounting supported	Yes
Product color	Silver
Flash modes	Red-eye reduction

Weight and Dimensions

Weight	210 g
