Kodak EasyShare DX4530 User Manual

7
Chapter 1
Turning On the Camera
1 Remove the lens cap.
If you do not remove the lens cap, it
comes off automatically when you turn
on the camera.
2 Turn the Mode dial from Off to any other
position.
The ready light blinks green while the
camera performs a self-check.
When the ready light glows steady green,
the camera is ready to take pictures (or
videos, if the mode dial is set to ).
In Still and Video modes, a status area
appears on the camera screen.
Changing the Display
AUTO
O
F
F
Ready light
Mode dial
OK
To Do This
Turn Liveview on so that the camera
screen can be used as a viewfinder
Press the OK button. To turn it off,
press the OK button again.
Change the Liveview setting so that it
is on whenever the camera is on
See page 51.
Turn the status area back on after it
times out
Press .
Turn off the camera
1 Turn the Mode dial to Off.
The camera completes
operations that are in process.
2 Replace the lens cap.

Kodak EasyShare DX4530 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Digital zoom	3.3 x
Optical zoom	3 x
Combined zoom	10 x
Focal length range	8 - 24 mm
Metering	automatic: multi-pattern TTL-AE
Interface	Dock Compatibility - KODAK EASYSHARE Camera Dock I, II and KODAK EASYSHARE Printer Dock 4000
Cable type	1 x A/V cable, 1 x USB cable
Minimum RAM	64 MB
Minimum processor	233 MHz
Dimensions (WxDxH)	111 x 66 x 39 mm
Camera shutter speed	1/2-1/1700 s
Minimum storage drive space	200 MB
Minimum system requirements	CD-ROM USB
Focal length (35mm film equivalent)	38 - 114 mm
Viewfinder type	Optical
Internal memory	32 MB
Compatible memory cards	mmc, sd
Display diagonal	1.8 \
I/O ports	1 x USB 1 x composite video/audio output 1 x docking station 1 x DC power input
Bundled software	KODAK EASYSHARE Software
Self-timer delay	10 s
Tripod mounting supported	Yes
Product color	Silver
Flash modes	Red-eye reduction

Weight and Dimensions

Weight	210 g
