Kodak EasyShare DX4530 User Manual

5
Chapter 1
Loading the Battery
1 Turn the Mode dial to Off.
2 On the bottom of the camera, slide the
battery door and lift to open.
3 Insert the CRV3 battery as shown.
4 Close the battery door.
Important Battery Information
The CRV3 battery is not rechargeable.
For acceptable battery life, and to make
sure your camera operates dependably, do
not use alkaline batteries.
NOTE: If AA batteries were included with your
camera, insert them as shown.
See page 13 for other types of batteries you can use in your camera.
If you purchased the Kodak EasyShare camera dock II, see page 64 for details
on installing the Kodak EasyShare Ni-MH rechargeable battery.
See page 95 for information on the optional Kodak 3-volt digital camera AC
adapter.
CRV3
AA

Kodak EasyShare DX4530 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Digital zoom	3.3 x
Optical zoom	3 x
Combined zoom	10 x
Focal length range	8 - 24 mm
Metering	automatic: multi-pattern TTL-AE
Interface	Dock Compatibility - KODAK EASYSHARE Camera Dock I, II and KODAK EASYSHARE Printer Dock 4000
Cable type	1 x A/V cable, 1 x USB cable
Minimum RAM	64 MB
Minimum processor	233 MHz
Dimensions (WxDxH)	111 x 66 x 39 mm
Camera shutter speed	1/2-1/1700 s
Minimum storage drive space	200 MB
Minimum system requirements	CD-ROM USB
Focal length (35mm film equivalent)	38 - 114 mm
Viewfinder type	Optical
Internal memory	32 MB
Compatible memory cards	mmc, sd
Display diagonal	1.8 \
I/O ports	1 x USB 1 x composite video/audio output 1 x docking station 1 x DC power input
Bundled software	KODAK EASYSHARE Software
Self-timer delay	10 s
Tripod mounting supported	Yes
Product color	Silver
Flash modes	Red-eye reduction

Weight and Dimensions

Weight	210 g
