Kodak EasyShare DX4530 User Manual

22
Chapter 2
Using the Auto Focus Framing Marks
For the best possible pictures, the camera attempts to focus on foreground
subjects (even if the subjects are not centered in the scene).
NOTE: Auto Focus framing marks appear only when the camera screen is
turned on. The framing marks do not appear in Landscape mode.
1 In any Still mode (except Landscape), press the OK button.
The camera screen turns on.
2 Press the Shutter button half-way to set the exposure and focus.
3 The Auto Focus framing marks depict the main focus area or areas. If the
camera is not focusing on the desired subject, release your finger,
recompose the scene, and repeat Step 2.
4 Continue pressing the Shutter button completely down to take the
picture.
While Shutter Button is Pressed Half-way
Center focus
Center wide focus
Side focus
Center and side focus
Left and right focus

Kodak EasyShare DX4530 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Digital zoom	3.3 x
Optical zoom	3 x
Combined zoom	10 x
Focal length range	8 - 24 mm
Metering	automatic: multi-pattern TTL-AE
Interface	Dock Compatibility - KODAK EASYSHARE Camera Dock I, II and KODAK EASYSHARE Printer Dock 4000
Cable type	1 x A/V cable, 1 x USB cable
Minimum RAM	64 MB
Minimum processor	233 MHz
Dimensions (WxDxH)	111 x 66 x 39 mm
Camera shutter speed	1/2-1/1700 s
Minimum storage drive space	200 MB
Minimum system requirements	CD-ROM USB
Focal length (35mm film equivalent)	38 - 114 mm
Viewfinder type	Optical
Internal memory	32 MB
Compatible memory cards	mmc, sd
Display diagonal	1.8 \
I/O ports	1 x USB 1 x composite video/audio output 1 x docking station 1 x DC power input
Bundled software	KODAK EASYSHARE Software
Self-timer delay	10 s
Tripod mounting supported	Yes
Product color	Silver
Flash modes	Red-eye reduction

Weight and Dimensions

Weight	210 g
