Kodak EasyShare DX4530 User Manual

65
Chapter 9
Docking the Camera
To transfer pictures and videos from the camera to the computer, or to charge
the battery:
1 Turn off the camera.
2 On the camera bottom, slide the connector
cover open.
3 Place the camera in the camera dock and
push down to seat the connector.
The Power/Transfer light glows
green when the camera is properly
seated.
The camera is now powered by the
camera dock instead of the camera
batteries.
NOTE: If a Kodak EasyShare Ni-MH rechargeable battery is installed in the
camera, the camera dock immediately begins charging.
Dock connector
door
Power/
Connector
Transfer
light

Kodak EasyShare DX4530 Specifications

General

Megapixel	5 MP
Sensor type	CCD
Digital zoom	3.3 x
Optical zoom	3 x
Combined zoom	10 x
Focal length range	8 - 24 mm
Metering	automatic: multi-pattern TTL-AE
Interface	Dock Compatibility - KODAK EASYSHARE Camera Dock I, II and KODAK EASYSHARE Printer Dock 4000
Cable type	1 x A/V cable, 1 x USB cable
Minimum RAM	64 MB
Minimum processor	233 MHz
Dimensions (WxDxH)	111 x 66 x 39 mm
Camera shutter speed	1/2-1/1700 s
Minimum storage drive space	200 MB
Minimum system requirements	CD-ROM USB
Focal length (35mm film equivalent)	38 - 114 mm
Viewfinder type	Optical
Internal memory	32 MB
Compatible memory cards	mmc, sd
Display diagonal	1.8 \
I/O ports	1 x USB 1 x composite video/audio output 1 x docking station 1 x DC power input
Bundled software	KODAK EASYSHARE Software
Self-timer delay	10 s
Tripod mounting supported	Yes
Product color	Silver
Flash modes	Red-eye reduction

Weight and Dimensions

Weight	210 g
