A-61796 September 2014 1-7
Rear view
1 Modem port — the RJ-11 port connects the fax modem to a phone line.
This is only for the Scan Station 730EX.
2 Security lock port — connects a security lock to the Scan Station. You
can purchase a standard security lock at an office supply store. Refer to
the instructions provided with the security lock for installation procedures.
3 Power port — connects the power cord/adapter to the Scan Station.
4 USB ports — connects peripheral devices (e.g., keyboard, mouse and
other accessories) to the Scan Station.
5 Ethernet port — connects the Scan Station to the network.
