- 20 -
KD 625-2 Workshop Manual_cod. ED0053029380_1° ed_ rev. 00
2
A
B
C
D
198
425
E
F
434
397
I
L
340
168
G
H
O
P
421
178
207
542
599
633
557
217
DIMENSIONI mm - MESURES mm - DIMENSION mm - EINBAUMAßE mm - DIMENSIONE mm - DIMENÇÕES (mm)
M
N
OVERALL DIMENSION
Technical information
KD 625-2
