Setting the stop limit stop
1) Remove the throttle lever cover.
1) Completely turn lever C counter-clockwise and keep it in this position.
Retainer F should not be in contact with lever C.
2) Unscrew nut G and bring retainer F in contact with lever C
3) Push retainer F so that lever C is moved backwards clockwise by
1.0 mm.
4) Lock retainer F by screwing nut G
Note: In this condition, the limit stops of the injection pump adjustment
rod will not be damaged by the violent impacts caused by the
possible assembly of electrostop.
Settings
Engine R.p.m.
Power
HP
(kW)
Specic fuel
consumption *
Time (sec)
per 100 cm
3
g/HP h
(g/kW h)
The indicated specic fuel consumption refers to the period following approximately 30 working hours.
Required settings (as most commonly applies)
KD 625-2
KD 625-2
KD 625-2
KD 625-2
KD 625-2
KD 625-2
EPA
KD 625-2
CE
