- 75 -
KD 625-2 Workshop Manual_cod. ED0053029380_1° ed_ rev. 00
7
170
1
2
Direct stop electromagnet
Features:
Operating tension
............................................ 12V.
Power coil absorption ...................................... 41 A.
Hold coil absorption
......................................... 0.5 A.
Setting:
- Screw drive rod 1 to the end of the thread on the electromagnet
piston.
- Excite the electromagnet and leave the stop lever in normal opera-
tion position.
- Bring drive rod 1 in contact with the stop lever and tighten lock nut 2.
Electric System
