Kohler KD 625/2 User Manual

- 73 -
KD 625-2 Workshop Manual_cod. ED0053029380_1° ed_ rev. 00
7
167
A
B
C
Electric System
Starting motor type Bosch DW (R) 12 V, 1.7 kW
RH direction of rotation.
A = 29.5÷31.5 mm
B = Ring gear plane
C = Flange plane
Caution – Warning
Flywheel should not project from ring gear plane B.
Characteristic curves of the 24 V 1.6 kW starting motor
The curves have been measured at a 20°C temperature with an 88 Ah battery.
V = Voltage to the motor terminals in Volt
P = Power in kW
C = Torque in N/m
N = Motor speed in rpm
J (A) = Absorbed current in Amperes.
