Chapter 3 Field Service
3-2
Scanner isolation (DIPSW 19-5)
This setting is used to disable the scanner function when it is not functioning correctly, while still
allowing the other functions to be used.
Job suspension / end at pulling out key counter (DIPSW 21-4)
Select either "Terminate" or "Interrupt" for printouts when the key counter has been removed for a
copier set to use the key counter.
Total counter / key counter increment operation (DIPSW 21-6)
This setting determines whether or not the number of prints or fax pages is added to both the total
count and key counter or just the total count, when the print controller is used.
Turn ON the sub power switch when the main power switch is turned ON (DIPSW 22-0)
When the print controller connected to the copier, the copier's sub power switch is ON when the
main power switch is ON, regardless of the setting of DIPSW22-0.
19-0 0 1
DIPSW No.
Use scanner function
can be used Isolated
19-5 0 1
DIPSW No.
Job suspension
Stop paper feed and
terminated
Stop paper feed and
printing is interrupted
21-4 0 1
Caution
When the setting for DIPSW 01-0 "Operation when key counter is removed" is
set to 1, it will be processed as a jam, even if the bit value for this setting
(DIPSW21-4) is changed.
DIPSW No.
Increment operation
Both the total counter
and key counter count up
Only the total counter
is counted up
21-6 0 1
Caution
The warm-up time increases when a copier is connected to the print controller.
In addition, this setting (DIPSW22-0) is set to 1 and cannot be changed. For
more information about this, refer to the copier's service handbook.
