Controls and Connections
Front Panel Controls
Thisdiagramshowsthelayoutofthefrontpanelknobs,switches,andbuons.
1
2
3
4
56 8
91011
12
13
7
1.
MASTER knob
2.
DRIVE knob
3.
OCTAVE switch
4.
Slider
5.
VCO 1
WAVEswitch
SHAPEknob
6.
VCO 2
OCTAVEswitch
PITCHknob
WAVEswitch
SYNC/RINGswitch
SHAPEknob
7.
MIXER
VCO1knob
VCO2knob
8.
FILTER
CUTOFFknob
RESONANCEknob
9.
EG
TYPEswitch
ATTACKknob
DECAYknob
INTknob
TARGETknob
10.
LFO
WAVEswitch
MODEswitch
RATEknob
INTknob
TARGETswitch
11.
SEQUENCER
TEMPOknob
KEYTRG/HOLDbuon
MOTION/SLIDE/
NOTEswitch
EDIT
 EDITMODEbuon
 WRITEbuon
 EXITbuon
SEQUENCER
 PLAYbuon
 RECbuon
 RESTbuon
 SHIFTbuon
Buons1–8
12.
PROGRAM/VALUE knob
13.
Display
