Korg MONOLOGUE User Manual

46
Button 13 (SCALE DUMP)
USER SCALE 1...6
ThistransmitsthemicrotuningthatwaseditedusingUSERSCALE1–6asa
generalSysExmessage.
Pressbuon13toselectthemicrotuningtotransmitviaSysEx.TurnthePRO-
GRAM/VALUEknobuntil"PressWRITE"isindicatedonthedisplay,andthen
presstheWRITEbuon.
USER OCTAVE 1...6
ThistransmitsthemicrotuningthatwaseditedusingUSEROCTAVE1–6asa
generalSysExmessage.
Pressbuon13toselectthemicrotuningtotransmitviaSysEx.TurnthePRO-
GRAM/VALUEknobuntil"PressWRITE"isindicatedonthedisplay,andthen
presstheWRITEbuon.
Button 15 (ALL DUMP)
Theseparametersallowyoutoperformadumpofalltheinternaldata,either
viaMIDIorviaUSB.
All Dump (USB)
TurnthePROGRAM/VALUEknobuntil“PressWRITE”isindicatedinthedis-
play.TheWRITEbuonwillblink.
PresstheWRITEbuontotransmittheMIDIdatadumpviatheUSBBconnec-
tor.Thedisplaywillindicatethemessage“Transmiing”.Thedatawilltake
about10secondstotransmit.
 IftheUSBcableisnotconnected,oriftheMIDIINportonthePCis
notopen,thedatawillnotbetransmied.
All Dump (MIDI)
TurnthePROGRAM/VALUEknobuntil“PressWRITE”isindicatedinthedis-
play.TheWRITEbuonwillblink.
PresstheWRITEbuontotransmittheMIDIdatadumpviatheMIDIOUT
connector.Thedisplaywillindicatethemessage“Transmiing”.Thedatawill
takeabout30secondstotransmit.

Korg MONOLOGUE Specifications

General

Product type	Analog synthesizer
Product color	Silver
User presets quantity	20
Keyboard number of keys	25
Preset programs quantity	80
Display type	OLED
Built-in display	Yes
Headphone outputs	1
Battery type	AA
Operating time	8 h
DC input voltage	9 V
Power source type	AC, Battery
Number of batteries supported	6

Weight and Dimensions

Depth	276 mm
Width	350 mm
Height	76 mm
Weight	1700 g
