VP-734 - Configuring the VP-734 via the OSD MENU Screens
7.5 The Setup Screen
Figure 17: Setup Screen
Setting
Function
Default
Save
Save setup to Profile 1 to Profile 8 or via USB to a memory stick
Recall
Recall setup from Profile 1 to Profile 8 or from a memory stick via
USB port
Erase
Erase a setup from Profile 1 to Profile 8
Frame Lock
Set to On or Off.
Frame Lock locks the vertical refresh rate of the output to that of the
input. Frame Lock only locks 50Hz or 60Hz/59.94Hz
In cases where the output resolution can support the vertical refresh
rate of the input, the output refresh rate will change according to the
input refresh rate
Off
Note that:
 Seamless switching is not possible when working in
the Frame Lock mode unless all sources are frame
synchronized
 If VP-734 can lock the input then the output will
follow
 If VP-734 cannot lock the input, then the output will
not change. The info menu will display one of the
following:
Sync Mode: Free Run (Frame Lock Off) or
Sync Mode: Frame Lock (Frame Lock On)
 When resetting the resolution to XGA or 720p,
Frame Lock will be turned off automatically and if
required you will need to turn Frame Lock on
