VS-44H2A – Introduction
3
Flexible Connectivity
• Analog and Digital Audio De-embedding (Extraction) – De-embeds the audio signal and
outputs it as balanced analog audio with separate volume control on each of the outputs
and S/PDIF digital audio.
• Flexible Content Protection – Selectable HDCP per input.
• Easy Installation – 19” enclosure for rack mounting a unit in a 1U rack space with
included rack ears and universal 100–240V AC power connection.
Typical Applications
The VS-44H2A is ideal for the following typical applications:
• Control rooms with multiple displays.
• Presentation and multimedia applications.
• Systems that require automatic HDMI routing.
Controlling your VS-44H2A
Control your VS-44H2A directly via the front panel push buttons, or:
• By RS-232 serial commands transmitted by a touch screen system, PC, or other serial
controller.
• Via the Ethernet using built-in user-friendly web pages.
DRAFT

Kramer VS-44H2A Specifications

General

Certification	CE, WEEE
Housing color	Black
On/off switch	Yes
Rack capacity	1U
Housing material	Aluminum
USB connector type	Mini-USB
HDMI input ports quantity	4
Ethernet LAN (RJ-45) ports	1
Built-in display	No
HDCP version	2.2
Product type	AV matrix switcher
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	RoHS
Harmonized System (HS) code	85299097

Weight and Dimensions

Depth	237.2 mm
Width	436.4 mm
Height	43.6 mm
Weight	2000 g
Package depth	330 mm
Package width	525 mm
Package height	107 mm
Package weight	2900 g
