10.2 Switching off the machine
Pos: 46.23 /Übersc hriften/Überschrif ten 3/U-Z/U nterlegkeile u nterlegen @ 35 0\mod_14367 93044774_78.d ocx @ 2628707 @ 3 @ 1
10.2.1 Putting Wheels Chocks Underneath
Pos: 46.24 /BA/Sic herheit/2. Vora ngestellte W arnhinweise/ Warnung - Masc hine sicher abst ellen ohne Tr aktor_Unterleg keile @ 278\m od_14049726442 11_78.docx @ 2083305 @ @ 1
WARNING!
Risk of injury due to the unsecured machine rolling away!
If the machine is not secured against rolling away when it has been switched off, there is a risk
of people being injured by the machine rolling away in an uncontrolled manner.
• Secure the machine against rolling away with wheel chocks.
Pos: 46.25 /BA/F ahren und Trans port/Rundballe npresse/Bild Un terlegkeile C omprima n eu @ 292\mod_1 41104900539 7_78.docx @ 230 2669 @ @ 1
1
Fig.
88
Pos: 46.26 /BA/F ahren und Trans port/Rundballe npresse/Te xt Pos. Unterleg keile Compri ma F/V x-treme @ 292\mod_1 411104706771_ 78.docx @ 2303 581 @ @ 1
The wheel chocks (1) are kept in a holder at the front left beside the drawbar. Each one is
locked in position in the holder by a spring clip.
Pos: 46.27 /BA/F ahren und Trans port/Rundballe npresse/Bild Un terlegkeile @ 350\mod_1 43679435364 7_78.docx @ 2628 962 @ @ 1
KR-1-081
1
Fig.
89
Pos: 46.28 /BA/F ahren und Trans port/Rundballe npresse/Text U nterlegkeile vor und hinter Rad _F_V_CF_CV _Fortima_Ulti ma @ 350\ mod_1436797289 399_78.docx @ 2629174 @ @ 1
• Park the machine on level and firm ground.
• To prevent the uncoupled machine from rolling away, place the wheel chocks (1) in front of
and behind the same wheel.
