34
Select Code to change the type of bar code you want to print. The printer dis-
plays the types of bar codes available. Use the left and right cursor keys to
move to the left of the option you want and press Enter. If an asterisk displays
to the left of the option, selecting it turns code off.
Depending on the bar code you have selected, some bar codes allow you to
choose whether to include a checksum and change the resolution at which the
bar code is printed as well as whether to print text or the checksum.
Select Text to print text as part of the bar code. Use the left and right cursor
keys to move to the left of the option you want and press Enter. If an asterisk
displays to the left of the option, selecting it turns text printing off. Text is printed
in the following manner:
• Code 39, Code 128, Interleaved 2 of 5 and MSI Plessey: text is printed
immediately beneath the symbol.
• EAN8, EAN13 and UPC: text for the number system is printed at the left
of the symbol; text for the product and manufacturer code is printed
beneath the symbol; text for the supplemental is drawn above
the symbol.
• PDF 417 has no text option.
Resolution specifies whether you want to print the bar code at normal or high
resolution. Use the left and right cursor keys to select the option you want and
press Enter.
CheckSum specifies the type of error checking you want to use. The type of
bar code selected at Code determines the prompt that displays next. For
example, if you selected 12 of 5, the following prompt displays:
Some bar code symbologies allow you to print the checksum value as part of
the bar code
