4 Description of the Pump (Set)
15 of 64
Etaline
4 Description of the Pump (Set)
4.1 General
▪ Non-self-priming in-line pump
▪ Handling clean or aggressive fluids not chemically and mechanically aggressive to
the pump materials.
4.2 Product Information as per Regulation No. 547/2012 (for water pumps
with a maximum shaft power of 150kW) implementing "Ecodesign"
Directive 2009/125/EC
▪ Minimum efficiency index: see name plate, key to name plate
▪ The benchmark for the most efficient water pumps is MEI ≥ 0.70.
▪ Year of construction: see name plate, key to name plate
▪ Manufacturer’s name or trade mark, commercial registration number and place
of manufacture: see data sheet or order documentation
▪ Product’s type and size identificator: see name plate, key to name plate
▪ Hydraulic pump efficiency (%) with trimmed impeller: see data sheet
▪ Pump performance curves, including efficiency characteristics: see documented
characteristic curve
▪ The efficiency of a pump with a trimmed impeller is usually lower than that of a
pump with full impeller diameter. Trimming of the impeller will adapt the pump
to a fixed duty point, leading to reduced energy consumption. The minimum
efficiency index (MEI) is based on the full impeller diameter.
▪ Operation of this water pump with variable duty points may be more efficient
and economic when controlled, for example, by the use of a variable speed drive
that matches the pump duty to the system.
▪ Information on dismantling, recycling and disposal after decommissioning:
(ðSection3.5,Page14)
▪ Information on benchmark efficiency or benchmark efficiency graph for
MEI=0.70(0.40) for the pump based on the model shown in the Figure are
available at: http://www.europump.org/efficiencycharts
4.3 Designation
Table5: Designation example
Position
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44
E T L - 0 3 2 - 0 3 2 - 1 6 0 - G G S A V 0 1 D 2 1 1 0 0 2 e x B K S B I E 3 P D 2 E M
See name plate and data sheet See data sheet
Table6: Designation key
Position Code Description
1-4 Pump type
ETL Etaline
ETLZ Etaline Z
5-16 Size, e.g.
032 Nominal suction nozzle diameter [mm]
032 Nominal discharge nozzle diameter [mm]
160 Nominal impeller diameter [mm]
17 Pump casing material
G Cast iron EN-GJL-250/ A48CL35
18 Impeller material
G Cast iron EN-GJL-250/ A48CL35
C Stainless steel 1.4408/ A743CF8M
