4 Description of the Pump (Set)
18 of 80
HPK
1121.8/06-EN
Mechanical seal with external circulation
(operating mode "E")
Uncooled, single, balanced mechanical seal
▪ Circulation from discharge nozzle to seal
cover
▪ Venting via circulation line in the
discharge nozzle
Circulation from discharge nozzle
Mechanical seal with air-cooled heat
exchanger
(operating mode "BL")
Uncooled, single, balanced mechanical seal
▪ Circulation via air-cooled heat exchanger
▪ Venting via vent valve on heat exchanger
Circulation IN/OUT
Single mechanical seal with steam/nitrogen
quench
Quench IN
Quench OUT
Mechanical seal in tandem arrangement with
quench liquid
Quench IN
Quench OUT
