KSB Omega User Manual

9.2.2 Vertically installed pump, installation type DJ
211
940.03
904
920.05
932
903.03
903.04
550.01
550.02
321
421.02*
411.01***
903.02
524.01
412.03
903.01
441
412.02
940.02
234
102
502
412.06
525.01
412.01
524.02
545
550.03 920.01
160
950
914.01
930.01
412.04
920.02
902.02
350.02
412.05
550.04
182
550.05
898.01
901.10
901.11
89-4.04
421.01**
350.01
901.04
360
901.16
471
904.02
920.08
593
433
525.02****
457.02
Fig. 36: General assembly drawing for installation type DJ
* For ATEX version labyrinth ring 423.02
** For ATEX version labyrinth ring 423.01
*** Does not apply to ATEX version
**** Does not apply to version with KSB mechanical seal 4OM
9 Related Documents
78 of 94
Omega / Omega V

KSB Omega Specifications

General

Application	Water supply, irrigation
Operating pressure	Up to 16 bar
Speed	2900 rpm, 1450 rpm
Connection Size	DN 32 to DN 400
Housing Material	Cast iron, stainless steel
Impeller Material	Bronze, stainless steel, cast iron
Seal Type	Mechanical seal
Operating Temperature	-10°C to +120°C
