13 SERVICE WORK ON THE CHASSIS 103
L01424-10
– Check the chain sliding guard for wear at the cutout.
»
When rivet
of the chain is no longer visible at the bottom edge
of the recess
of the chain sliding guard:
– Change the chain sliding guard.
– Check that the chain sliding guard is firmly seated.
» If the chain sliding guard is loose:
– Tighten the chain sliding guard.
Guideline
Screw, chain sliding guard M5 5 Nm (3.7 lbf ft)
