ENGINE

145

18.3.15

Relloving

the

liming

chain

guide

rail

Remove

screw . Take

off

timing

chain guide rail toward the top.

18.3.18

Relloving

the

liminll

chain

tensioning

rail

Remove

screw .

Remove

the

timing

chain tensioning rail from

above.

18.3.17

Relloving

the

liminE

chain

securing

guide

Remove

screws . Take

off

the timing chain securing guide.

18.3.18

Relloving

the

liminll

chain

- Take

off

the timing chain.

•

Info

I Identify the direction of travel.

18.3.1

Relloving

the

ipition

pulse

lIenerator

Remove

screws

- Pull the cable support sleeve from the engine case. Take

off

the crankshaft position

sensor.
