6
FORK,
TRIPLE
CLAMP
16
6.1.6
Loosening
the
lark
protector
6.1.7 Positioninl
the
lark
protection
6.1.8
Relloving
the
lark
IBIS
-
Remove
screws and remove the clamp.
-
Remove
screws
on
the left fork leg.
Push
the fork protector downwards.
-
Remove
the screws
on
the right fork leg.
Push
the fork protector downwards.
- Position the fork protection
on
the left fork leg. Mount and tighten screws
Guideline
1 Remaining screws, chassis
110
Nm
(7.4
Ibf
fl)
1
- Position the wiring harness.
- Position the brake line. Put the clamp
on,
mount and tighten screws
- Position the fork protection
on
the right fork
leg.
Mount and tighten the screws.
Guideline
I Remaining
screws,
chassis
110
Nm
(7.4
Ibf
It)
1
Preparatory
work
-
Remove
the headlight mask with the headlight.
('
r
p.
99)
-
Raise
the motorcycle with the
lift
stand. (r
p.
12)
-
Remove
the front wheel. (r
p.
103)
Main
work
-
Remove
screws and take off the clamp.
-
Remove
cable binder
-
Remove
screws and take off the brake caliper.
- Allow the brake caliper and brake line
to
hang tension-free to the side.
(EXC
EUJAUS,
XC-W)
- Release screws . Take out the left fork leg.
- Release screws . Take out the right fork leg.
(EXC
USA)
- Release screws . Take out the left fork leg.
- Release screws . Take out the right fork leg.
