6 FORK, TRIPLE CLAMP
• If the measured value is greater than the specified value:
- Reduce the thickness of the preload spacer.
•
If the measured value is less than the specified value:
- Increase the thickness of the preload spacer.
6.1.17 Assemblinl the compression dampinl fittinl
• Info
I The steps are identical for both fork legs.
- Clamp the compression damping fitting in a bench vise using soft jaws.
- Mount a·ring
and seal ring
-
Grease the a·ring.
1 Lubricant
(Tl58) ( .. p. 292)
- Mount shim stack
• Info
I Mount the smaller shims below.
- Mount pistons with a·ring
• Info
I The side with the largest inside diameter faces upward.
20070!>-1O
Grease the piston a·ring.
1
Fork oil (SAE 4) (48601166S1) ( .. p. 291)
- Mou nt washer .
- Mount spring with the tighter coil facing downward.
- Mount and tighten nut
Guideline
1 Compression damping
fitting nut
1 M6xO.5
13 Nm (2.2 Ibf ft)
• Info
25
I The washer must have freedom of movement relative to the spring force .
• 200705-10
- Secure the nut by locking.
- Extract the compression damping fitting.
6.1.18 Assemblinl the canridle
• Info
I The steps are identical for both fork legs.
- Clamp in the piston rod.
1 Clamping stand
(Tl4016S) ( .. p. 305)
- Mount valve of the rebound damping, with the spring and a·ring.
-
Grease the a·ring.
1 Lubricant
(Tl58) ( .. p. 292)
- Mou nt spri ng
