18
ENGINE
147
-
Take
out
dowels
.
Take
off clutch
cover
gasket
18.3.23
Rellovlng
the
clutch
discs
-
Remove
screws
-
Take
off spring retainer
-
Take
off spring
washer
-
Take
off
pretension
ring
-
Take
off
pressure
cap
-
Completely
remove
clutch disc
pack
-
Remove
clutch
pressure
piece
