9
SHOCK
ABSORBER,
SWINGARM
67
9.13
Disassemblinglhe
damper
Preparatory
work
-
Remove
the spring. (r
p.
66)
Main
work
- Note down the present state
of
rebound damping and compression damping
- Completely
open
the adjustment elements of the rebound damping and compres-
sion damping.
-
Remove
rubber cap of the reservoir.
- Slowly unscrew screw
,/
The pressurized nitrogen is bled off.
-
Remove
locking cap
-
Press
seal ring retainer all the way in with the special tool.
I Disassembly tool
(Tl216)
(r
p.
304)
-
Remove
lock ring
•
Info
I
Do
not scratch the inner surface.
- Take out the damper.
-
Remove
screw . Drain the oil.
