KTM 690 - Page 93

WIRING DIAGRAM 91
Components:
A6 CDI controller
B1 Throttle valve sensor TPS
B2 Temperature sensor for indicator lamp
L1 Pulse generator
L2 Ignition coil
Cable colors:
15 orange
32 brown
33 brown
34 blue
35 yellow
36 black
37 gray
38 black-blue
39 gray
40 black-brown
50 black-yellow
132 black-yellow
