WIRING DIAGRAM 93
Components:
A1 Roadbook
A2 not assigned
A3 not assigned
A4 GPS (optional)
A5 Iritrac (optional)
B3 Wheel speed sensor
H1 Right rear flasher
H2 Left front flasher
H3 Left rear flasher
H4 Right front flasher
H5 Brake / tail light
H6 Additional rear light (optional)
H7 Parking light
H8 ICO Light (optional)
H10 Roadbook light
H11 Low beam
H12 High beam
H13 Horn
H14 Additional rear light (optional)
H15 Flasher indicator light
H16 Idling speed indicator lamp
H17 Indicator lamp for the coolant temperature
H18 High beam indicator light
H19 Oil pressure indicator lamp
K2 Flasher relay
P1 Speedometer
S1 Rear brake light switch
S3 Oil pressure sensor
S7 Front brake light switch
S8 Flasher switch
Cable colors:
19 yellow
25 white-yellow
26 blue
28 green-orange
29 green
31 blue-orange
40 black-brown
43 brown
45 white
46 white-green
47 white-green
48 yellow-blue
49 green-gray
50 black-yellow
54 brown
57 black-red
58 black-red
59 white-green
60 black-green
61 green-red
