10. - Maintenance and storage
KN270BGB_F
Mower conditioner
 The Gyrodine gearbox
Upper gearbox:
- Place the cutterbar in horizontal position.
- Remove plugs (1) and their seals.
- Pour prescribed oil quantity and quality in the
cutter bar:
• h: From 2 mm (0.08’’) to 3 mm (0.11’’).
- Top up if necessary.
- Clean and reinstall filler plugs (1) and their seals.
Replace if necessary.
H
1
1
h
Before draining oil, operate the machine for a
few minutes so that the oil warms up.
FC302G - FC302GI - FC352G
Oil volume 1 L (0.26 US gal)
Type of oil Mineral oil (Gear oil)
Viscosity SAE80W90
Specification API-GL5 (extreme pressure)
When changing the oil, it is recommended to use either an identical mineral oil or a synthetic oil of type
PAO (Poly-Alpha-Olefine) with viscosity grade SAE75W90.
