Front Panel Features
1-2
Front Panel Features
Category
Buttons
Channel/Parameter
Buttons
Value Buttons
KB3
LED
LCD
Contrast
Display
Alpha
Wheel
Mode &
Function
Buttons
Zone &
Programmable
Buttons
Control Sliders
Shift
Button
& LEDs
Shift, Sw, and Zone Buttons and Control Sliders
Master Volume slider—Adjusts the overall volume.
Setup Zone buttons—Pressing a Zone button will mute or unmute the zone. Zones are the
independent regions of the keyboard that make up a Setup.
Sw button—Depending on the current mode (Program or Setup), the Sw button can be
programmed to do a variety of functions.
