Kurzweil SP5-8 Service Manual

Diagnostic Test Modes
Display and Front Panel Buttons
3-2
Display and Front Panel Buttons
In the Diagnostics menu, the display shows the currently selected test, test modes, actions,
and test results.
Press the Chan / Param Up or Down button to move through the available tests. To select a
test, press the Next button. Press a Chan / Param Up or Down button to select the Test Mode:
Run Once, Loop or Continuous. Then press the Next button to begin the test. While some
tests are processing, shows in the display.
Some tests have additional test options. In this case, use the Chan / Param Up or Down
button to move through the available test options and press the Next button to choose the
option and run the test. To return to the previous menu or option, press the Previous button.
To return to the Boot Loader, press the Previous button.
Test Results
At the completion of an individual test, the display shows the results of the test; the test name
and for a passed test or for a failed test. When a test fails, additional lines of
test results may scroll across the display. Use the Chan / Param Down button to review each
line of test results.
Diagnostic Test Modes
Run Once
The Run Once test mode allows you to select and run an individual test. With
selected in the display, press the Next button to select and run the test once.
At the completion of a test, whether pass or fail, press the Previous button to exit the test and
return to the Diagnostics menu.
To exit the Diagnostics menu, press the Previous button to return to the Boot Loader.
Loop
Loop continuously runs an individual test. The display continuously displays the number of
tests performed in the run eld ( ), and displays the number of failed tests performed in
the fail eld, ( ).
Loop stops if a failure is detected.
Continuous
Continuous is the same as Loop, but does not stop if a failure is detected. Continuous runs
the selected test until you press the Previous button.

Kurzweil SP5-8 Specifications

General

Keyboard number of keys	88
MIDI-keyboard number of keys	- keys
Product color	Black
Pitch bend wheel	Yes
Interface	USB
Headphone outputs	1
Input voltage	15 V
Power source type	DC
Power consumption (typical)	15 W

Weight and Dimensions

Depth	350 mm
Width	1392 mm
Height	120 mm
Weight	21000 g
