Kurzweil SP5-8 Service Manual

6-1
Chapter 6
Replacement Parts
Printed Circuit Boards and Assemblies
Part No. Description
101010643001 Engine PCB
1010302970 Right Front Panel PCB
1010302990 Left Front Panel PCB
1010600770 Power Switch Assembly
101040072001 LCD Assembly
1010900760 Automatic Shutdown (ERP Control) PCB
6990001390 Keyboard Assembly 88 LK40GH+AFT
N093LK10L6 LK Key Contact PCB LO
N093LKW0M7 LK Key Contact PCB MID
N093LKW0H8 LK Key Contact PCB HI
Keyboard Assembly
Part No. Description
N093LKW005 Key Contact Strip (12 positions)
N093LKW011 Key Natural Low A
N093LKW012 Key Natural Hi C
N093LKW013 Key Sharp
N093LKW014 Key Natural A
N093LKW015 Key Natural B
N093LKW016 Key Natural C
N093LKW017 Key Natural D
N093LKW018 Key Natural E
N093LKW019 Key Natural F
N093LKW020 Key Natural G
N093LK2030 LK Sharp/Black Hammer
N093LK2031 LK Natural/White Hammer

Kurzweil SP5-8 Specifications

General

Keyboard number of keys	88
MIDI-keyboard number of keys	- keys
Product color	Black
Pitch bend wheel	Yes
Interface	USB
Headphone outputs	1
Input voltage	15 V
Power source type	DC
Power consumption (typical)	15 W

Weight and Dimensions

Depth	350 mm
Width	1392 mm
Height	120 mm
Weight	21000 g
