9.DRIVE AND DRIVEN PULLEYS
9-13
Mongoose/KXR 250
INSTALLATION
Install the clutch/driven pulley and driven
belt onto the drive shaft.
Install the clutch outer, collar and washer.
Hold the clutch outer with the flywheel
holder.
Install and tighten the clutch outer nut.
Torque: 5.0～6.0kg-m
Universal Holder E017
Keep grease off the drive shaft.
＊
Special
