KYMCO Mongoose/KXR 250

10.FINAL REDUCTION/
TRANSMISSION SYSTEM
10-8
Mongoose/KXR 250
Inspect shift shaft gear.
Damage → Replace.
Inspect shift shaft.
Damage/bends/wear → Replace.
Remove the main axle.
MAIN AXLE DISASSEMBLY
Remove the washers, collar, primary driven
gear, bush and clutch dog.
Shift Shaft Gea
r
Shift Shaf
t
Main Axle
Colla
r
Washe
r
Primary Driven Gea
r
Clutch Dog
Washers
Primary Driven Gea
r
Clutch Dog
Colla
r
Main Axle
Bush
