14. FRONT WHEEL/FRONT SUSPENSION/
STEERING SYSTEM
14-6
Mongoose/KXR 250
Install the distance collar.
Install the right new bearing and dust seal
into the front wheel hub.
Oil seal and bearing install E014
INSTALLATION
Reverse the “FRONT WHEEL HUB
REMOVAL AND INSPECTION”
procedures.
Tighten the front wheel hub nut.
Torque: 5.0～6.0kgf-m
Be sure the tapered side of the distance
collar face the wheel.
＊
Apply the grease onto the oil seal lips,
bearing.
＊
• Do not allow the bearings to tilt while
driving them in.
• Do not strike the center race or balls of
the bearing. Contact should be made
only with the outer race.
• Pack all bearing cavities with grease.
• Drive in the bearing squarely with the
sealed end facing out.
＊
Special
Apply grease onto the bearing and dust
seal lips of the wheel panel.
＊
Distance Colla
To Next Page
