15. REAR WHEEL/AXLE/SUSPENSION
15-10
Mongoose/KXR 250
INSTALLATION
Reverse the “REAR WHEEL/AXLE/AXLE
HUB REMOVAL AND INSPECTION”
procedures.
Install the rear axle hub.
Install the rear axle.
Connect the drive chain.
Install the rear brake disk, collar inner nut,
washer and outer nut.
Install the rear wheel hub and tighten the
nut.
Torque: 9.0～11.0kgf-m
Install cotter pin (new)
Apply grease onto the dust seal lips and
bearings.
＊
At this time, the rear axle hub should not
be tightened completely.
Final tightening is done after the chain
slack adjustment.
＊
At this time, the nuts should not
be tightened completely.
＊
Do not loosen the wheel hub nut after
torque tightening. If the wheel hub nut
groove is not aligned with the cotter pin
hole, align groove with the hole by
tightening up on the wheel hub nut.
Always use a new cotter pin.
＊
