KYMCO Mongoose/KXR 250

2. FRAME COVERS/EXHAUST MUFFLER
2-4
Mongoose/KXR 250
Remove the three bolts at the rear fender.
Remove the two screws attaching the right
and left floor board.
Remove the two screws attaching the frame
body and three screws attaching the outlet
hose, then remove the rear fender.
HANDLEBAR COVER REMOVAL
Remove the two screws at the handlebar
cover.
Disconnect the indicator lamp coupler, then
remove the handlebar cover.
Bolts
Screws
Screws
Screws
Screws
During removal, do not pull the joint
claws forcedly to avoid damage.
＊
Outlet Hose
Indicator Lamp couple
r
