2. FRAME COVERS/EXHAUST MUFFLER
2-5
Mongoose/KXR 250
CENTER FRAME COVER REMOVAL
Remove the seat. (See page 2-3)
Remove the fuel fill cap.
Remove the four bolts at the center frame
cover, then remove the center frame cover.
FRONT FENDER REMOVAL
Remove the seat (See page 2-3), right and
left side frame cover (See page 2-3) and
center frame cover. (See page 2-5)
Remove the two bolts at the front fender left
side.
Remove the two screws attaching the inlet
hose.
Remove the two bolts at the front fender
right side.
Remove the screw, then remove the drive
select grip from the drive select lever.
Bol
t
s
Bol
t
s
Select Grip
Bol
t
s
Screw
Screws
After remove, be sure to tighten the fuel
fill cap.
＊
Fuel Fill Cap
