KYMCO Mongoose/KXR 250

2. FRAME COVERS/EXHAUST MUFFLER
2-6
Mongoose/KXR 250
Disconnect headlight and ignition switch
couplers, then remove the front fender.
RIGHT AND LEFT FLOOR BOARD
REMOVAL
Remove the four screws at the floor board,
then remove the floor board.
FRONT CARRIER REMOVAL
Remove the four bolts at the front carrier,
then remove the front carrier.
Ignition Couple
r
Headlight Couple
r
Screws
Bolts
